Diaphragm vacuum and pressure pumps

As a top manufacturer on the diaphragm pump's business, Electro A.D. provides an undoubted quality awarded with more than 35 years of experience that we put in practice every day to offer the most efficient, safety and reliable products for our customers.

Electro A.D. is a family business which values have been transmitted to the team through the years and continue to be. Values of collaboration and development with clients, suppliers, social and public entities. We are also proud to provide our finest and nearest personal treatment.

This ideas along with the product, brought EAD to the top as the first Spanish company in its sector.

CHARITY

NEW FACTORY
Electro AD is proud to announce that on December 2016 we collaborated again with the National Food Bank by making a food donation for a total of 5,300€ value. We remain aware of the difficulties some fellow citizens still face and will keep taking this kind of actions in the future. This food is basically used for guaranteeing basic nutrition needs of people who are passing through difficult times. As we know it is not possible to give all the help that we would like but it is a small detail that may change in a high way a lot of lives. We take care of our team but also try to collaborate as much as possible to improve our society and this is just another small example. [See documents].

Small actions all together, may create big changes.

EAD just started the construction of new facilities that will enable the business to grow. An extra 2.000m² will accommodate its sales and R&D&I teams, as well as hightech resources commensurate with the firm’s enormous prospects for growth.



QUALITY

CORPORATE VIDEO
Since January 2007 Electro A.D. is worthy of ISO-9001 certificated for its quality management and also has a wide range of products CSA certified.

Electro AD is proud to announce that we already have a corporate video in order to show all of you our business, our way to work diaphragm pumps, our values and objectives. We hope you enyoy it!




OUR HISTORY

1976, OUR ORIGINS

Electro A.D. is a family project started in 1976 as a result of the vision of Antonio Donado and Petra Muñoz. Later in 1986 EAD established itself as a limited company and began its internationalization. By 1990 EAD had already achieved an important participation in the Italian market.

Our pump’s heads incorporated a system that keeps shutters well fixed and also allows our product to have one of the highest specifications in the sector worldwide. This improvement among others eliminated many of the problems encountered by producers when the pumps were used in extreme conditions of vacuum, pressure or steam, as well as resulted in a much longer lifetime than other vacuum pumps’ manufacturers.

Back in 1993 and thanks to the success and acceptance of its products, EAD began negotiations with several companies to start the distribution of its pumps in France, Germany and Holland. All of these agreements let us achieve important market shares thanks to the price, quality of products and a unique treatment and collaboration between supplier and clients.

1996,THE LAUNCH OF HX10P3

In 1996 EAD began manufacturing the HX10P3 family using plastic materials which allowed a reduction in weight and dimensions of the pumps, once again transforming the diaphragm vacuum market. This model, initially designed for a top worldwide producer of dental devices soon became one of the most requested pumps by our clients.

1998, RESEARCH, DEVELOPMENT AND INVESTIGATION DEPARTMENT

Already in 1998 Franc, Oscar, Alex and Antonio (the founder’s sons) started to manage production and sales areas, and went on to create a technical area focused on the development and improvement of products.

As a result of the new ideas coming from these young minds, the development of the new designs started to play an important role. Later in year 2000 this technical area became the R+D+I Department which develops its way of work based on continuous feedback, encouraging the participation of employees, customers and suppliers. Electro A.D. developers began to improve existing products and increase our pump’s portfolio.

2004, THE BIRTH OF EVO SYSTEM

Year 2004 was a key year for the developing team as the company was already established with an export share that reached around 80% of its turnover. At this growing point designers initiated the patent of a new system which was set to allow automatic parallel and serial connections of heads with just one inlet and one outlet, avoiding annoying external unions. This development is called the EVO System.

The new system started from the standard HX10P3 model and the experience acquired with time and important feedback. EVO pumps then went to fully satisfy the guidelines which EAD had set out for its developments. Offering a compact lightweight product with high standards of durability and efficiency, 100% recyclable and above all an state-of-the-art product nice to look at.

AT PRESENT...

Nowadays Electro A.D. products are an important referent in the world of diaphragm pumps but we’re still not satisfied. Electro A.D. has set itself a new challenge; we want to become your reliable and trusty diaphragm vacuum pumps supplier for any need you may have.

Will you join us into the future?

1975
1980
1985
1990
1995
2000
2005
2010
1976: EAD creation
1986: EAD becomes a Limited Company
1993: Internalization in France, Germany and Holland
1996: Launch HX10P3
1998: Antonio and Petra's sons start managing EAD
2000: R+D+I Department
2004: EVO SYSTEM



















Electro A.D. has more than 30 different models that will guarantee the best option for your application.





INSTALLATION AND USER MANUAL
CHEMICAL COMPATIBILITY GUIDE

Check the characteristics of every model and select your type of pump:
AIR & GAS PUMPS
AIR & GAS PUMPS
LIQUID PUMPS
LIQUID PUMPS

PHOTOMODELVACUUMPRESSUREFLOWVOLTAGEDATASHEET
NEO-ISERIES -906 mbar1,2bar4 LPMDC
PARALLEL -773 mbar1,5 bar7 LPM
NEO-826 mbar1bar4 LPMDC
MR-813 mbar1,55bar7,5 LPMDC
SR-813 mbar1,55bar 8 LPMDC
ZR-867 mbar1,2bar8,5 LPMDC
ZR BRUSHLESS-867 mbar1,2bar6 LPMDC
MRP3SERIES -920 mbar > 3 bar7 LPMDC
PARALLEL -800 mbar1,5 bar14 LPM
SRP3SERIES -920 mbar> 3 bar7 LPMDC
PARALLEL -800 mbar1,5 bar14 LPM
ZRP3SERIES -920 mbar> 3 bar7 LPMDC
PARALLEL -800 mbar1,5 bar14 LPM
EVOR-960 mbar> 2 bar12 LPMDC
SR10-786 mbar1,1bar16 LPMDC
SR10 BRUSHLESS-826 mbar1,3bar14 LPMDC
SR10P3SERIES -933 mbar> 1,5 bar13 LPMDC
PARALLEL -766 mbar> 1 bar25 LPM
EVO10R-946 mbar> 2 bar23 LPMDC
H5-813 mbar1,6 / > 2 bar6 LPMAC
S5-813 mbar1,6 bar6 LPMAC
Z5-867 mbar1,2 bar6,5 LPMAC
H5P3SERIES -946 mbar> 3,5 bar6 LPMAC
PARALLEL -813 mbar1,6 bar12 LPM
Z5P3SERIES -960 mbar> 2 bar6,5 LPMAC
PARALLEL -867 mbar1,2 bar13 LPM
S5P3SERIES -946 mbar> 3,5 bar6 LPMAC
PARALLEL -813 mbar1,6 bar12 LPM
EVO5-960 mbar> 2 bar10,5 LPMAC
C5-813 mbar1,6 / > 2 bar6 LPMAC
H10-813 mbar1,4 bar14 LPMAC
HX10-05-833 mbar> 1,8 bar13 LPMAC
HX10P3-05SERIES -960 mbar> 2 bar13 LPMAC
PARALLEL -826 mbar1,6 bar25 LPM
EVO10TYPE1 -960 mbar> 2 bar24 LPMAC
TYPE2 -960 mbar1 bar20 LPM
H30-866 mbar > 2 bar20 LPMAC
H30P3SERIES -960 mbar> 2 bar25 LPMAC
PARALLEL -880 mbar1 bar48 LPM
EVO30TYPE1 -960 mbar> 1 bar44 LPMAC
TYPE2 -960 mbar>2 bar38 LPM
PHOTOMODELVACUUMPRESSUREFLOWVOLTAGEDATASHEET
NEO-ISERIES -360 mbar16 m H2O0,3 LPMDC
PARALLEL -200 mbar12 m H2O0,6 LPM
NEO-225 mbar12 m H2O0,3 LPMDC
MR-350 mbar18 m H2O0,65 LPMDC
MRP3SERIES -520 mbar25 m H2O0,7 LPMDC
PARALLEL -350 mbar20 m H2O1,1 LPM
H5-325 mbar18 m H2O0,55 LPMAC
H5P3SERIES -520 mbar25 m H2O0,7 LPMAC
PARALLEL -350 mbar20 m H2O1,1 LPM
X
X
Please fill out the questionnaire and as soon as possible a comercial will answer you. If you know which Electro AD specialist can answer your doubts you can send directly an email to her (you can find all the emails on the CONTACT tab). Thank you for trusting us.

Company Name:


Personal name:


Email:


Description:

SEND


EAD VALUES WITH OUR CLIENTS
SPEED OF DELIVERIES
In Electro A.D. we perceive the importance of speedy deliveries. For this reason one of our basics is to deliver orders always on time and adapting as much as possible to the customer’s demands. As our products are tailor made we try to keep our subassemblies, raw material, processes and personnel ready for any last minute need from our clients.
QUALITY CONTROL
Electro A.D. submits its products to the strictest tests guaranteeing a product of great quality and durability in the worst working conditions.
  • Electrical tests carried out by ABAG certified equipment.
  • Elasticity tests of rubber components with INSTRON certified equipment.
  • Noise tests to detect levels outside of the range considered acceptable.
  • Technical Specifications as vacuum and flow of every pump that we sell are checked and registered by our Technical and Production Departments.
  • Several other specific tests under request.
CUMSTOMIZED PRODUCTS
For us in Electro A.D. the product is as important as our client. For this reason, our experienced staff is always available and ready to offer joint solutions with the highest level of technology.
X
EAD VALUES WITH OUR PLANET
THE ENVIRONMENT
We perceive the damaging effects that the industry globally is causing to the environment. For this reason our products as well as our processes look to decrease to a minimum all the environmental pollution and other negative effects.

With this idea in mind in 2011 we had set up a 69kW solar installation over the roof of our facilities.

We create what will come!

SUSTAINABILITY
The concept of sustainability embraces the present and the future at the same time and goes along with the full act of responsibility and commitment of all. Harmful actions today will compromise the life and growth of future generations as it affects the entire planet. Our company is focused on developing all its acts and projects according to a respectful and sustainable non written law which is common sense. Always thinking in our planet and environment considering each fact that may affect direct or indirectly to it.


This is our declaration of principles.

LATEST NEWS

COMPAMED 2017
DATE: 02/11/2017

Electro A.D. announces its participation in the 2017 edition of Compamed where we will present our range of products for medical and other fields. We invite you to visit us between the 13th and 16th of November.






OPTICAL FIBER IN EAD
DATE: 15/05/2016

Electro AD has become the first business in all Masquefa to improve their internet connection to optical fiber. With this higher infrastructure we can communicate one hundred times faster with the world and therefore enhance the service that we offer.

The Mayor of Masquefa visited our industry and inaugurated this important event for all businesses in this city. [See press release]
CHARITIES
DATE: 25/10/2017

Electro AD is happy to announce that in the last months we have collaborated with the national food bank and the local food bank by making a total donation of 5000 Euros. This money is basically used for guaranteeing basic nutrition needs of people who are passing through difficult times. As we know it is not possible to give all the help that we would like but it is a small detail that may change in a high way a lot of lives. We take care of our team, but also we try to collaborate as much as possible to improve our society and this is just another small example.

Small actions all together, may create big changes.

Electro AD wants to help and improve our society, that’s why the company has been involved in helping the most needed people directly. [See documents]



NEW WEBSITE
DATE: 31/07/2015

Currently we are changing the face of our website and we apologize for any error you may find. Now you can use tablets or mobile phones to visit our web. We will try to add more options and funcionalities to help the relationship between Electro A.D. and our clients. Thank you for you understanding.
CLIENT SATISFACTION SURVEY
DATE: 04/01/2015

As we understand the importance of our clients’ feelings related to our services we consider quite important to receive continuous feedback from our customers. To make it as easy as possible now you can evaluate Electro A. D. in less than five minutes by clicking the link below. Thank you very much for you opinion.




CORPORATE VIDEO
DATE: 01/07/2015

We are so proud to announce that we have created a corporative video with the purpose of showing our company, processes and working methods. You can watch it in the HOME page.

THE EVO-LUTION
DATE:02/03/2004


Electro A.D. has expanded its range of products from the current generation with the presentation of the EVO family. Obtaining high vacuum levels and flow rates, increasing even more the pump’s durability and improving the handling of important loads of liquid. This system has been and still is a reference to other manufactures.




AUTOMATIC SCREWDRIVER
DATE: 20/11/2014

Our Company just introduced to its production line an automatic screwdriver to ensure the correct torque for the screws of several pump's heads. Speed and torque are permanently checked and registered aiming always to improve our global quality.
